The multi-sides bending center is the flexible solution for all kinds of metal box or metal cubes processing. It supports with a wide range of positive bending processing. The only one manual operation which is the positioning and loading. We also offer the solution with robert loading and unloading. The whole process no need the labor intervention which max improve the production efficiency and repeatability quality. It is the smartest choice with real high return on investment.
•The entire bending process no need human intervention.
• Super Fast speed Auto-bending process, Bending workpieces of different shapes, sizes and materials, "0" second adjustment time, ensuring high production efficiency.
• Ensure high quality and high repeatability
• Extremely low unit cost, extremely high return on investment
• Applied universal bending molds which can meet the demands of quantity processing
• Automatic press adjustment device, which can meet the needs of batch production or small-volume production of multiple varieties
• Unique intelligent compensation technology MAC2.0, which enables the equipment to adapt to changes in the plate and external environment
• Built-in robot loading and unloading integrated interface
• Equipped with Internet technology lOT
If you are looking for a machine that can meet your multi-sided bending needs, the BC series will be your best choice: fully automatic, easy to use. It can bend and process various workpieces with high efficiency and quality.
Based on our rich experience in automated multi-sides bending machine for many years, this new multi-sided bending center can perform flexible bending on the punched and sheared plates, and can automatically complete multi-sides bending with only one positioning; manual operation is only required when loading and unloading. The BC series has a set of universal and universal bending molds, which are controlled by self-developed software.
Item | unit | BC25 | BC30 | |
Plate length min.-max. | mm | 270~2500 | 370~3000 | |
Plate width min.-max. | mm | 270~1500 | 200~1500 | |
Maximum diagonal size | mm | 2915 | 3354 | |
Maximum bending height | mm | 220 | 220 | |
Maximum bending speed (s/knife) | s/c | 0.3 | 0.3 | |
Number of axes | pc | 21 | 21 | |
Work surface height | mm | 900±30mm | 900±30mm | |
Angle range | mm | -135~135 | -135~135 | |
Conventional bending sheet thickness | Carbon Steel | mm | 0.3~2.0 | 0.3~2.0 |
304 Stainless Steel | mm | 0.3~1.5 | 0.3~1.5 | |
201 Stainless Steel | mm | 0.3~1.5 | 0.3~1.5 | |
Aluminum Plate | mm | 0.3~3.0 | 0.3~3.0 | |
Bending process | Automatic tool change | Automatic tool change | ||
Minimum height of bending plate | 5 times the plate thickness T | 5 times the plate thickness T | ||
Gas consumption | L/min | 5 | 5 | |
Air source pressure | Mpa | 50.6 | 50.6 | |
Dimensions | mm | About：3800×5000×2200 | About：4500×5000×2200 | |
weight | T | 20 | 24 | |
