The Swiss-type CNC lathe machine which integrates the multi tools holder, main Spindle tools and Turret with one structure. It can quickly perform turning, milling, drilling, tapping, and side milling operations. It’s best of your choice for processing the small and complex parts. Currently we can offer the solutions for processing the bar with diameter of 20/26/32, with 3AXIS/5AXIS/6AXIS for a variety of processing demands.
1. The background and brief introduction of our Swiss lathe
As so called swiss type lathe, so why it is called swiss type lathe? To answer this question, we should look back to the history of this special technology. Swiss lathes were originally designed by Swiss watchmaker Jakob Schweizer to produce extremely small parts for the watchmaking industry. The first Swiss-style lathe was developed in the 1870s but it started gaining popularity in other industries in the 1960s thanks to its high precision and low margin of error. In this background, we named it with swiss type lathe which is specialized for processing the small and precision parts.
As a company striving into this industry with more than 20 years. We founded our company and made our first generation with simple version in 1990s. After two generation’s efforts, we have been grown up with the first three leading manufacturer for the Swiss type lathe. In the domestic Chinese west and south market our machines won a super high reputation and repurchase rate. We adhere to the high quality product and good after-sales services,
2. The main introduction of SA-series Swiss lathe
Our SA series Swiss Type Lathe which combines sliding tools and turret which is multi tool holders, main spindles, sub-spindles and rotating tool axes are fully integrated on structure. It can quickly perform turning, milling, drilling, tapping, and side milling operations . This makes it the perfect choice for processing small and complex parts.
3. The advantages of Swiss type lathe
The advantages of using a Swiss lathe to produce parts are numerous. These machines reduce deflection in long and thin parts to increase accuracy and reduce cycle times. It can perform both milling and turning for more versatility. A machine may have as many as 28 tools mounted on it at one time to provide single-process machining.
4. The applications of Swiss lathe and the typical samples
Swiss lathes are widely used in the production of medical devices and implants, where precision and bio-compatibility are critical.
Typical Samples:
- Surgical instruments (e.g., bone screws, surgical pins, and needles)
- Dental implants and components
- Orthopedic implants (e.g., hip and knee joint parts)
- Catheter components
- Microfluidic devices
Aerospace Industry
The aerospace industry requires parts that can withstand extreme conditions, such as high temperatures and pressures, while maintaining precise dimensions.
Typical Samples
- Turbine blades and components
- Fuel system components (e.g., nozzles, fittings)
- Fasteners and connectors
- Sensor housings
- Actuator components
Automotive Industry
Swiss lathes are used to produce small, high-precision components for engines, transmissions, and fuel systems.
Typical Samples:
- Fuel injector parts
- Valve components
- Transmission shafts and pins
- Connectors and fittings
- Sensor housings
Electronics Industry
The electronics industry relies on Swiss lathes for producing small, intricate parts used in consumer electronics, telecommunications, and semiconductors.
Typical Samples:
- Connector pins and sockets
- Micro-screws and fasteners
- Sensor components
- Heat sink components
- Semiconductor parts
Watchmaking and Jewelry Industry
Applications: Swiss lathes are ideal for producing tiny, high-precision components used in watches and jewelry.
Typical Samples:
- Watch gears and screws
- Jewelry clasps and fittings
- Decorative components
- Micro-engraved parts
Defense and Firearms Industry
Applications: Swiss lathes are used to manufacture precision components for firearms and defense equipment.
Typical Samples:
- Gun barrels and triggers
- Firing pins
- Small ammunition components
- Optical mounts and fittings
General Manufacturing
Applications: Swiss lathes are also used in general manufacturing for producing small, high-precision parts for various applications.
Typical Samples:
- Hydraulic and pneumatic fittings
- Shafts and pins
- Custom fasteners
- Prototyping of small components
5. What is important before you choose your swiss type lathe
-Machining and Assembling technology
The good machining and Assembling technology is quite vital for the cnc swiss type lathe. As the leading manufacturer for CNC Swiss lathe with around 20 years. We have the sufficient quality inspection system from the machining to the assembling. And also our experts with sufficient knowledge of different industry which can offer professional turnkey solutions for valuable customer.
-Tools selection modules
We offers the rich tool selection modules according to your industry applications.This can be flexible and customized with your processing demands.
-Guide Bushing
The guide bushing supports the part at a distance from the collet. During machining, the bar material is clamped in a collet that can slide along behind the guide bushing which can minimize the tailing material. More over, With this special design, Such mechanical configuration prevents any significant deflections during machining the thin and long parts
-Faster Cycle Times for Complex Parts
Our swiss type lathe feature between 3 and 6 axes(currently) and can perform multiple operations on the part in a single machining cycle; thread cutting, end-face grooving, drilling, slotting, milling, cut-off, and back drilling in a single path
